STANDARD FEATURES

AXLES	DEXTER 10,000LB OIL BATH
BRAKE	(2)ELECTRIC BRAKES
COUPLER	30K 2 5/16" ADJUSTABLE COUPLER
CROSS MEMBER	3" CHANNEL 16" CENTERS
FENDERS	N/A
FLOOR	2"X6" TREATED WOOD FLOOR
FRAME	HD MAINFRAME I-BEAM XMEMBERS
FRAME FLOOR	6" X 8.2 CHANNEL SIDE RAILS
FRAME MAIN	HIGH TENSILE 12" I-BEAM 22LB/FT
FRAME NECK	I-BEAM
JACK	(2 SPEED)25000LB SPRING LOADED DROP LEG JACK
LIGHTS	LED LIGHTS ENCLOSED STEEL BOXES
MOUNT	SPARE TIRE MOUNT RECESSED IN NECK
PAINT	* PPG URETHANE 4:1 PAINT
RAILING	N/A
RAMP	OPTIONAL FOR FLAT DECKS
SAFETY	DOT REFLECTIVE TAPE/ 1/4" SAFETY CHAINS
STORAGE	FRONT TOOLBOX WITH LOCKABLE LID
TIE DOWN	STAKE POCKETS ON 16" CENTERS WITH RUB-RAIL
TIRES	(8) 235/80/R16 10-PLY
TONGUE	N/A
WHEELS	16" DUAL WHEELS (8-LUG)
WIRING	SEALED HARNESS THROUGH FRAME

OPTIONAL FEATURES

12K AXLE UPGRADE HYDRAULIC DISC BRAKE (exchange)

12K AXLE UPGRADE HYDRAULIC DRUM BRAKE (exchange)

12K AXLE UPGRADE ELECTRIC BRAKE (exchange)

5' WOOD DOVETAIL (2) SPRING ASSIST FOLD UP RAMPS

SLIDING RATCHET 4" STRAP

SLIDING RATCHET TRACK

ADD 3RD 7K AXLE (electric)

7'-9' SLIDE IN RAMPS AVAILABLE FOR NON DOVETAIL TRAILERS

HYDRAULIC JACK OPTION UPGRADE

17.5" WHEELS AND 16 PLY TIRES UPGRADE (exchange)

235/85/R16 14 PLY TIRE UPGRADE (exchange)

HYDRAULIC DRUM BRAKE UPGRADE

HD 4.27 STEEL GRATE EXPANDED METAL FLOOR

1/8" DIAMOND PLATE FLOOR

3/8" D-RINGS (specify location)
