Single Axle
Multi-Purpose Utility Trailers WT SERIES SIDE GATE GVWR 2990#
Size & Model
| 6'X12' | WT126-24FMRSG |
| 6'X14' | WTHD146-40FMRSG |
| 6'10"X12' | WT12610-24FMRSG |
| 6'10"X14' | WTHD14610-40FMRSG |
STANDARD FEATURES
| AXLES | DEXTER 3500LB AXLES |
| BRAKE | N/A |
| COUPLER | 2" BULLDOG STYLE COUPLER |
| CROSS MEMBER | L2X2X3/16" ON 20"C |
| FENDERS | 1/8" DIAMOND PLATE |
| FLOOR | 2X6 TREATED PINE |
| FRAME | L3X5X5/16" MAINFRAME |
| JACK | 2000LB TOP WIND JACK WITH SAND FOOT |
| LIGHTS | LED LIGHTS ENCLOSED STEEL BOXES |
| MOUNT | SPARE TIRE MOUNT |
| PAINT | PPG URETHANE 4:1 |
| RAILING | 2SQ11GA. SQUARE TUBE TOP RAIL (16" TALL) |
| RAMP | (2) BIFOLD 48" |
| SAFETY | DOT SAFETY CHAINS |
| TIE DOWN | 3/8" ROD CORNER TIE DOWNS |
| TIRES | 205-75-15 6PLY |
| TONGUE | C3X3.5 CHANNEL WRAP TONGUE |
| WHEELS | 15" SILVER MOD WHEELS (5 ON 5-LUG) |
| WIRING | SEALED HARNESS RAN THROUGH FRAME |
OPTIONAL FEATURES
| EXTRA ELECTRIC BRAKE | |
| CASTER WHEEL FOR JACK | |
| SWIVEL JACK | |
| CLOSED IN TOOLBOX BETWEEN JACKS | |
| BOARD CHANNELS | |
| SPARE TIRE WHEEL | |
| HD 4.27 STEEL GRATE EXPANDED METAL FLOOR | |
| 1/8" DIAMOND PLATE FLOOR | |
| 3/8" D-RINGS (specify location) | |
| 11 GA. SOLID SMOOTH SIDES | |
| 14 GA. SOLID SMOOTH SIDES | |
| CUTOUTS FOR STAKE POCKETS | |
| EXPANDED METAL SIDES |
