Single Axle
Multi-Purpose Utility Trailers WT HD SERIES GVWR 4000#
Size & Model
| 6'X10' | WTHD106-40FMR |
| 6'X12' | WTHD126-40FMR |
| 6'10"X10' | WTHD10610-40FMR |
| 6'10"X12' | WTHD12610-40FMR |
| 6'10"X14' | WTHD14610-40FMR |
STANDARD FEATURES
| AXLES | DEXTER 5200#LB AXLE |
| BRAKE | NONE |
| COUPLER | 2" BULLDOG STYLE COUPLER |
| CROSS MEMBER | L3X3X3/16 ON 16"C |
| FENDERS | 1/8" DIAMOND PLATE |
| FLOOR | 2X6 TREATED PINE |
| FRAME | L3X3X1/4" ANGLE |
| JACK | 5000LB DROPLEG SAND FOOT |
| LIGHTS | LED LIGHTS ENCLOSED STEEL BOXES |
| MOUNT | SPARE TIRE MOUNT |
| PAINT | * PPG URETHANE 4:1 PAINT |
| RAILING | 2SQ11GA. SQUARE TUBE TOP RAIL (16" TALL) |
| RAMP | 48" BI-FOLD REAR RAMP GATE |
| SAFETY | DOT REFLECTIVE TAPE/ 1/4 |
| TIE DOWN | STAKE POCKETS CENTER OF EVERY SECTION |
| TIRES | (2)NEW 225/75/R15 8-PLY |
| TONGUE | C4X4.5 WRAP TONGUE |
| WHEELS | 15" 6 LUG |
| WIRING | SEALED HARNESS RAN THROUGH FRAME |
OPTIONAL FEATURES
| DOUBLE BARRELL SPRING ASSIST | |
| CASTER WHEEL FOR JACK | |
| SWIVEL JACK | |
| TONGUE TOOLBOX WITH LOCK | |
| 60" WIDE X 48" LONG SIDE GATE (14' TRAILER ROD) | |
| 48" SPRING ASSIST NON BI-FOLD (UPGRADE) | |
| 48" NON BI-FOLD REAR RAMP (UPGRADE) | |
| BOARD CHANNELS | |
| 1/8" DIAMOND PLATE FLOOR | |
| 3/8" D-RINGS (specify location) | |
| 14 GA. SOLID SMOOTH SIDES | |
| CUTOUTS FOR STAKE POCKETS | |
| EXPANDED METAL SIDES |
